Start measurement with “Quick start guide”
-
Start measurement with “Quick start guide”
Select the
recording item
Select the
wiring system
(1) Select the item you want to record.
* The number of selected items will have effect on file size and
also on max recording time.
(3) Connect to the circuit to be tested.
* Read and follow the safety precautions
described in the instruction manual.
(4)(5) Check the Test environment.
* Self-diagnosis, wiring check and detection of connected
sensors will be performed in this test.
* It is recommended to do this test for ensuring the testing
conditions are correct. It takes about 10 seconds.
See P.27.
See P.
KEW6315
- 39 - KEW6315
with “Quick start guide”
Confirm the
connections
Check the test
environment
Select the item you want to record.
The number of selected items will have effect on file size and
also on max recording time.
Check the Test environment.
diagnosis, wiring check and detection of connected
* It is recommended to do this test for ensuring the testing
conditions are correct. It takes about 10 seconds.
See P.42.
See P.41.
See P.37.
(2) Select the wiring system to be
measured.
* Select a proper wiring system for accurate
measurements.
