10.2 General specification KEW6315
- 131 - KEW6315
Backlight (Press the LCD Key to turn off, press any key other than “Power” to turn on.)
PQ measurement : IEC 61000-4-30 Ed.2 Class S
Dimension : 175(L)×120(W)×68(D)mm
Weight : approx. 900g (including batteries)
Accessories : V test leads MODEL7255 (red, white, blue, black) with alligator clip — 1 set
Power cord MODEL7169 ——————————————————————————————————————————————————— 1 pce
USB cable MODEL7219 ———————————————————————————————————————————————————— 1 pce
Quick manual —————————————————————————————————————————————————————————————————— 1 pce
CD-ROM ———————————————————————————————————————————————————————————————————————— 1 pce
PC software for setting and data and data analysis
(KEW Windows for KEW6315)
Instruction manual data (PDF file)
Alkaline size AA battery (LR6) ————————————————————————————————————————————— 6 pcs
SD card M-8326-02 —————————————————————————————————————————————————————————— 1 pce
Carrying case MODEL9125 ———————————————————————————————————————————————— 1 pce
Input terminal plate ——————————————————————————————————————————————————————————— 1 pce
Cable marker —————————————————————————— 8-color x 4pcs each (red, blue, yellow,
green, brown, gray, black, white)
Optional parts : Clamp sensor
MODEL8128 (Clamp sensor 50A ø24mm)
MODEL8127 (Clamp sensor 100A ø24mm)
MODEL8126 (Clamp sensor 200A ø40mm)
MODEL8125 (Clamp sensor 500A ø40mm)
MODEL8124 (Clamp sensor 1000A ø68mm)
MODEL8129 (Flexible sensor 3000A ø150mm)
MODEL8130 (Flexible sensor 1000A
ø110mm)
MODEL8146 (Leakage sensor 10A ø24mm)
MODEL8147 (Leakage sensor 10A ø40mm)
MODEL8148 (Leakage sensor 10A ø68mm)
MODEL8141 (Leakage sensor 1A
ø24mm)
MODEL8142 (Leakage sensor 1A ø40mm)
MODEL8143 (Leakage sensor 1A ø68mm)
Instruction manual for Clamp sensor
Carrying case with magnet MODEL9132
Power supply adapter MODEL8312 (CAT.III 150V, CAT.II 240V)
Accuracy :within ±5 sec/ day
Power source : AC power supply
Voltage range AC100V(AC90V) - AC240V(AC264V)
Frequency 50Hz(47Hz) - 60Hz(63Hz)
Power consumption 7VAmax
: DC power supply
Dry-cell battery Rechargeable battery
Voltage DC3.0V
(1.5V×2 in series × 3 in parallel)
DC2.4V
(1.2V×2 in series × 3 in parallel)
Battery Size AA Alkaline (LR6) Size AA Ni-MH (1900mA/h)
Current consumption 1.0A typ.(@3.0V) 1.1A typ.(@2.4V)
Battery life *ref. value at 23ºC 3 hours: Backlight OFF 4.5 hours: Backlight OFF
* with fully charged batteries
