KEW6315 10.2 General specification
KEW6315 - 132 -
Real-time OS :
This Product uses the Source Code of T-Kernel under T-License granted by the T-Engine Forum
(www.t-engine.org) Portions of this software are copyright (c) 2010 The FreeType Project (www.freetype.org).
All rights reserved.
External communication function : USB * USB cable length: 2m max.
Connector mini-B
Communication method USB Ver2.0
USB identification no. Vendor ID: 12EC(Hex)
Product ID: 6315(Hex)
Serial no.: 0+7 digit individual no.
Communication speed 12Mbps (full-speed)
: Bluetooth
®
Communication method Bluetooth
®
Ver2.1+EDR Class2
Profile SPP
Frequency 2402 - 2480MHz
Modulation method GFSK(1Mbps), π/4-DQPSK(2Mbps), 8DPSK(3Mbps)
Transmission system Frequency-hopping system
Digital output terminal :
Normally, it is set to “High”. It changes to “Low” while the measured values are exceeding the thresholds
set for each power quality event. Usually, it is fixed to “High”, but changed to “Low” if the duration of an
event is less than 1 sec. This is applicable to the events with the highest-priority only. To adjust the
generating outputs to the events with low-priority, select “OFF” for the events with higher priority than the
desired event.
* [Priority order]: Transient -> INT -> Dip -> Swell -> Inrush current
Connector Terminal block with 6-polarity (black, red, gray ML800-S1H-6P)
Output format Open collector output, Low active
Input voltage 0 - 30V, 50mAmax, 200mW
Output voltage High:4.0V-5.0V, Low:0.0 - 1.0V
