1.1 Functional overview
-
Inst/ Integration/ Demand
Display the avg/ max/ min instantaneous values of
voltage/ active power/ apparent power/ reactive power.
Integration values also can be viewed by switching screens.
Moreover, demand values with the preset target value can
also be checked.
See “6.1 Inst “W” (P.92), 6.2 Integration “Wh” (P.
6.3 Demand (P.102) ” for further details.
Vector and Wiring check
Vectors of voltage and current per CH are displayed
on a graph. Executing wiring check function is
possible from this screen.
See “
Chap. 1 Instrument overview
1.1 Functional overview
Start/ Stop
Choose either “Quick start guide” or “Start now” to start
recording. Can do simple and fast start-up setting by
selecting “Quick start guide”.
See “4.6 Recording procedures” (P.37) for further details.
KEW6315
- 11 - KEW6315
/ max/ min instantaneous values of current/
power.
Integration values also can be viewed by switching screens.
Moreover, demand values with the preset target value can
(P.100),
Vector and Wiring check
Vectors of voltage and current per CH are displayed
on a graph. Executing wiring check function is
possible from this screen.
See “6.4 Vector” (P.105) for further details.
Chap. 1 Instrument overview
” to start
up setting by
for further details.
