KYORITSU 6315 Instruction Manual User Manual
Page 54
KEW6315
Wiring connection
KEW6315
- 52 -
Clamp sensor direction for correct measurement:
● Confirm that the wiring system selected with the instrument and of the measured line are harmonized.
● Ensure that the arrow mark on the clamp sensor points towards to load side.
* Reverse clamping switches the symbols (+/-) for active power (P).
Arrow mark:
Point towards load side.
Load
Power
source
