Self-diagnosis
If “NG” judgment is given frequently, there might be something wrong with the instrument.
instrument and refer to “Chap.11 Troubleshooting
Sensor detection
If the detection result is NG, each sensor type will be displayed in red.
Criteria of judgment and cause
Check
Type of
current sensor
- Types of the connected current sensors are harmonized? Types of the current
sensors used for measurements
???
(cause unknown)
- Current sensors are firmly connected to the
- If any failures are in doubt:
Exchange the connections of the sensors and test again.
Connect the current sensor, for which "NG" is given, to the CH on which
another sensor is properly detected.
If the result "NG" is given
suspected. A defect of sensor is suspected if "NG" is given for the same
sensor connected to another
Stop using the instrument and the sensor, if any defects are in doubt, and
refer to "Chap. 11 Troubleshooting
Start measurement with “Quick start guide”
44 -
If “NG” judgment is given frequently, there might be something wrong with the instrument. Stop using the
oting” (P.157) .
If the detection result is NG, each sensor type will be displayed in red.
Causes
Types of the connected current sensors are harmonized? Types of the current
measurements should be the same.
sensors are firmly connected to the instrument?
If any failures are in doubt:
Exchange the connections of the sensors and test again.
Connect the current sensor, for which "NG" is given, to the CH on which
another sensor is properly detected.
If the result "NG" is given for the same CH, a defect of the instrument is
suspected. A defect of sensor is suspected if "NG" is given for the same
another CH.
Stop using the instrument and the sensor, if any defects are in doubt, and
Troubleshooting" (P.157) in this manual.
