KEW6315 Recording method
KEW6315 - 74 -
Recording method
“Interval”
Set the interval to record the measured data on the SD or internal memory. Seventeen different intervals are
available, but it cannot be set to a longer time than the demand measurement cycle. The preset recording
interval may be changed automatically according to the selected demand measurement cycle. Please refer
to “Settings of demand measurement” (P. 59) in this manual.
Selection
1 sec/ 2 sec/ 5 sec/ 10 sec/ 15 sec/ 20 sec/ 30 sec/
1 min/ 2 min/ 5 min/ 10 min/ 15 min/ 20 min/ 30 min/
1 hour/ 2 hours/ 150,180 cycles (approx. 3 sec)
* Default setting is highlighted in gray.
* The intervals: 150, 180 cycles (approx. 3 sec) are the ones defined in IEC61000-4-30. Data will be collected
in 150 cycles at 50Hz (nominal frequency) and in 180 cycles at 60Hz (nominal frequency).
Move the blue highlight to “Interval”. Show the list of the intervals.
Select a desired interval. Confirm. Cancel.
