1.3 Constructional drawing
Size AA alkaline dry-cell
battery (LR6) or
Size AA Ni-MH
rechargeable battery
AC Voltage input
1.3 Constructional overview
14 -
Current input
Power cord
Digital output (1 ch) to recorder or alarm
Analog input (2 ch) from thermometer
or illuminometer
SD card
PC
USB
