GDM-8261 User Manual
50
Amplifier Output
INPUT
V W
COM
V
V
o
T
AMP
V
o
AC Noise
DC offset
DC Power Supply Output
DC output
DC
Power
Supply
INPUT
V W
COM
V
AC ripple V
T
DCV DCI

Monitor the voltage and current
present on a component in a circuit
or the output voltage and current of
a DC power supply.
Monitor Voltage and Current
INPUT
V W
V
A
LO
COM
0~1.2A
0~10A
Load
DC
Power
Supply
