SCANNER (OPTIONAL)
101
S
CANNER (OPTIONAL)
The optional scanner, GDM-SC1, lets you effectively
measure multiple channels connected to a single
GDM-8261 DMM.
ACV
SCAN
DCV
STEP
Installation GDM-SC1 Scanner Specifications ........................ 102
Configure Scanner ................................................ 102
Select Channel Group and Enable Scanner .......... 104
Connect Wires ...................................................... 105
Insert Scanner ...................................................... 107
Scanner Configuration Record .............................. 109
Setup Overview .............................................................. 110
Setup Simple Scan ............................................... 111
Setup Advanced Scan ........................................... 113
Use External Trigger ............................................. 116
Run Overview .............................................................. 117
Run Scan/Step ..................................................... 117
Recall Scan/Step Result ....................................... 118
Setup and Run Monitoring ................................... 118
