4-5
SM MX100-01E
Troubleshooting
1
2
3
4
5
6
7
Trouble Action Item Relevant Modules
Fluctuation in the measured value Check Power supply frequency and integration
time do not match
MX110
Replace 4WRTD CTRL Board MX110-V4R-M06
Replace 4WRTD Scanner Board MX110-V4R-M06
Replace 4WRTD Terminal Board MX110-V4R-M06
Check/replace Wire Assembly (Power-CPU)
Power supply frequency detection
MX100
Check Noise MX110
Replace H04 Input CTRL Board MX110-UNV-H04
Replace H04 Input PWR Board MX110-UNV-H04
Replace H04 Input AD Board MX110-UNV-H04
Replace H04 RJC Board MX110-UNV-H04
Replace M10 Input Contorl Board MX110-UNV-M10
Replace M10 Scanner Board MX110-UNV-M10
Replace DCVDI Terminal Board MX110-UNV-M10
Replace M10 RJC Board MX110-UNV-M10
Replace Strain Ctrl Board MX112
Replace Strain Clamp Scan Board MX112-B12-M04
Replace STR CRP TM 120 Board MX112-B12-M04
Replace STR Clamp Scan Board MX112-B35-M04
Replace STR CRP TM 350 Board MX112-B35-M04
Replace STR NDIS Scan Board MX112-NDI-M04
Replace Terminal Assembly MX112-NDI-M04
Replace DI Power Board MX115
Replace DI Input Board MX115-D05-H10
Replace 24VDI Input Board MX115-D24-H10
Replace DCVDI Terminal Board MX115-D24-H10
Contact output does not output Replace DO Power Board MX125
Replace DO Relay Board MX125
The output value is not correct Replace AO Power Board Assembly MX120-VAO-M08
Replace AO Ctrl Board Assembly MX120-VAO-M08
The output pulse interval and duty amplitude are
not correct
Replace PWM Ctrl Board Assembly MX120-PWM-M08
Replace PWM Power Board Assembly MX120-PWM-M08
4.3 Troubleshooting Checklist
