6.11 10-CH Screw Terminal Block (772061)
Customer Maintenance Parts List
Yokogawa Electric Corporation
Copyright Apr. 2003(YK).1st Edition:Apr.2003(YK) CMPL 772061-01E
1
2 3 4
5 6 7 8
12 11 10 9
15 14 13
15
14
Name Plate 1 B9237AS
Screw 2 B9900SG
1 Terminal Cover Assembly 1 B9237AF
Qty Part No.
B9237AG
Item
2
Terminal Cover
Description
1
B9900SG 1 Screw
3
9
B8720DP
B8720CF
B8720TG
B8720TJ
B8720JD
B8720HD
B8720DN
Y9306LS
B8722EH
B8720DQ
1
1
1
1
1
1
1
1
1
1
Terminal Door
Terminal Cover
M10 Screw Terminal Board
M10 RJC Board
Sheet
Bracket
Terminal Base
B,H,Screw.M3x6
Spring
Latch
4
5
6
7
8
10
11
12
13
Note:
· Parts marked with a symbol are Customer Maintenance Parts (CMP) .
· The contents of this CMPL are subject to change without prior notice as a result
of confinuing inprovements to the instrument’s performance and functions.
