Main module – Yokogawa PC-Based MX100 User Manual
Page 9
1-2
SM MX100-01E
Main Module
The main module is equipped with a power supply connector, a power switch, an
Ethernet port, a CF card slot, and other parts. It contains functions such as the power
supply to and the control of each input/output module, communications with a PC, data
storage to the CF card when communication is disconnected.
Ethernet port
Power switch
CF card
slot
Power connector
