1.11 Functions of the 8-CH, Medium-Speed Analog
Output Module
The module has eight outputs for voltage or current.
An external power source (24 V) is required for current output.
For voltage output only, an external power source is not required.
For details, see the user’s manual (IM MX100-01E or IM MW100-01E).
Input terminal (clamp terminal)
Terminal cover
Terminal Assignments
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
V+
-
I+
V+
-
I+
V+
-
I+
V+
-
I+
+
-
V+
-
I+
V+
-
I+
V+
-
I+
V+
-
I+
+
-
CH1
CH2
CH3
CH4
Vext
CH5
CH6
CH7
CH8
Vext
