Yokogawa PC-Based MX100 User Manual
Page 169
7-29
SM MX100-01E
Procedures for Disassembly
1
2
3
4
5
6
7
7.
Pull the Module case in the direction of the arrow to remove it.
Module case
Module case
8.
Remove the Stud and Screw from the rear panel.
Stud
Stud
Right side
Rear panel
9.
Remove the 4 screws from the left and right sides.
7.6 Disassembling the MX120 Medium-Speed Analog Output Module and the Medium-Speed PWM Output Module
