Page 503: Syntax, Systems, Set diffserv plp -15
Document No. 10-300090, Issue 1
23-15
80-Series QoS
set diffserv plp
* Important:
This command is for future functionality and is not
currently supported.
Command Mode
Global Configuration.
Description
Assigns a packet loss probability (PLP) to a DiffServ code point (DSCP).
Syntax
set diffserv plp {low | high} dscp
* Note:
While the PLP for a DSCP can be configured and displayed, the
PLP is applied only when RED is enabled on a port.
Systems
■
P550R and P880, 80-series modules only.
■
P580 and P882.
Table 23-7. Parameters, Keywords, Arguments
Name
Definition
{low | high}
The PLP that you want to assign.
The first DSCP in the range of DSCPs that
you want to assign the PLP to. DSCPs range
from 0 to 63.
[
The last DSCP in the range of DSCPs that you
want to assign the PLP to. DSCPs range from
0 to 63.
