Avaya P580 - Manual (Page 283)

Document No. 10-300090, Issue 1 13-17
IPX
Sample Output The following example:
■
sets the IPX RIP filter precedence to 5
■
sets the start-network to 2
■ sets the end-network to 3
■
applies filters to RIP packets in both directions (both)
■
adds the network to the routing table (allow)
■
sets the filter ticks to 10000
■
sets the filter hops to 5
on an interface labeled “boston”.
(config-if:boston) # ipx rip-filter 5 2 3 both allow 10000 5
Systems P550R, P580, P880, and P882.
Modify the number of ticks to get to the network in the
routing table (inbound RIP packets) or in the advertised
information (outbound RIP packets). The range is 0 to 32000
ticks.
Modify the number of hops to get to the network in the
routing table (inbound RIP packets) or in the advertised
information (outbound RIP packets). The range is 0 to 16
hops.
Table 13-6. Parameters, Keywords, Arguments
Name Definition
2 of 2
