Manual Range Function
1. After completing initial start-up, you
may select RANGE from the Analyze
mode main menu to select a range.
2. When you press RANGE , the screen
directs you to select from auto or fixed
(manual) range. Press
FIXED to select
the manual range mode.
3. After pressing FIXED , the screen directs
you to use the UP and DOWN buttons to
scroll through the fixed oxygen concen-
tration ranges. The default setting of the
current range is displayed. Press
ACCPT to select the default, or select
another range first by scrolling.
4. When you press ACCPT to set the
desired range, the screen returns to the
Analyze mode main menu. The last line
indicates the range selection and mode.
Stand-by Mode
The Stand-by mode allows the user to:
A. Perform a normal shutdown.
B. Change the background gas selection.
C. Change the sample/span gas source connections.
D. Reset the analyzer to the factory-installed default span and zero
offset values.
E. Change the authorization code.
VALVES: ANALYZE T=25C C=9:59
FLO W = 150.0 CC/M IN
AUTORANGE: 10 PPM
1 2 3 4 5
RANGE ALRM R
5.00
PPM 02
SETUP STDBY CAL
VALVES: ANALYZE T=25C C=9:59
SELECT AUTO-RANGE OR
FIXED-RANGE FO R O2.
1 2 3 4 5
AUTO FIXED ESC
VALVES: ANALYZE T=25C C=9:59
SET FIXED O2 RANGE: 50 PPB
1 2 3 4 5
UP DOW N ACCPT ESC
VALVES: ANALYZE T=25C C=9:59
FLOW = 150.0 CC/MIN
MAN RANGE: 10 PPM
1 2 3 4 5
RANGE ALRM R
5.00
PPM 02
SETUP STDBY CAL
