A Page A - 2 TANK SENTINEL ® INSTALLATION GUIDE
Electrical Specifications
Console Line Voltage
115 VAC +15%, –10% (standard)
230 VAC +15%, –10% (special order
...standard with
T8
export orders)
a UPS (Uninterruptable Power Supply) is
required for Emergency Backup
Generator Applications (see Chapter 7).
Frequency & Power
50 / 60 Hz 100 Watts maximum
1 Amp maximum at 115 VAC, or
0.5 Amp maximum at 230 VAC...
WARNING Match the line voltage
power ratings – on the Serial Number
label – when wiring to the console input
power terminals. Avoid voiding the
warranty and equipment damage –
DO NOT use incorrect voltage sources.
Memory Backup Battery
3 volt, Lithium (P/N BR2032 3V,
INCON P/N 390-0004). Acceptable
voltage = 3.2 to 2.8 VDC (2 to 10
years depending of the duration of all
power outages).
LLDI Line Leak Detector Interface ( T1 T2 ):
1 to 8 TS-LLD RS 485 interface
LLDI Dispenser Interface:
RS 485 (dBox/dispenser dependent)
Discrete Inputs ( T1 T2 ):
2 (for dry relay contacts only). Used
typically for Emergency Backup
Generator Applications (run input
signal... see
Note above & Chapter 7
for details).
Alarm Relay Output Contacts:
(2) Form C, SPDT, 120/240 VAC,
30 VDC, 3 Amps – resistive loads
Input/Output modules ( T2 ) * :
1 to 16 with optional 8 channel TS-IEM
(Internal Expansion Module). The maximum
ampacity of an output module installed here
is 1 Amp up to 250 volts. See TABLE 7.2.
Serial Communications Ports (2) RS232:
Requires Standard EIA (Electronic Industry
Association) RS232C devices:
Comm Port 1
9 pin – Female connector (for DTE
devices, or a PC).
Comm Port 2
9 pin – Male connector (for DCE
devices, or modem).
Internal Fax/Modem (Optional) *
RJ11 connector port provided
Environmental Specifications
Storage Temperature –4° to 140° F (–20° to
60° C) w/o Thermal Printer Paper
Operating Temperature 32° to 122° F
(0° to 50° C)
Operating Humidity 0 to 95 %,
non-condensing
Cleaning (console)
Cloth, or sponge slightly dampened
in mild detergent
Splash Resistance Not to be exposed to direct
spray, splash, or drips
Console Location Indoors: office, or
nonhazardous industrial environment (out-
doors within a Nema 4 enclosure –
T4 )
WARNING The Tank Sentinel console
must be mounted in a location where
explosive, or flammable vapors are not
present otherwise, an explosion hazard
will be created which can result in
property damage, injury, and death.
—
❖ —
* = Contact factory for availability
NOTE
T1
*
*
