3 Page 3 - 4 TANK SENTINEL ® INSTALLATION GUIDE
Reference Figures 3 - 1 and 3 - 2. Use the appropriate Formula below, to find the
Tilt value for each Tank (the sign of XF changes depending on which figure is
used)... N represents a Tank number, and an asterisk ( * ) means multiply by:
(LF – LP)* XP (LF – LP)* XP
Tilt N = per Figure 3 - 1 per Figure 3 - 2
XP + XF XP – XF
(
PROBE AND FILL ON OPPOSITE SIDES OF TANK CENTER
) (
PROBE AND FILL ON SAME SIDE OF TANK CENTER
)
( ) ( )
Tilt 1 = = Tilt 2 = =
( ) ( )
( ) ( )
Tilt 3 = = Tilt 4 = =
( ) ( )
( ) ( )
Tilt 5 = = Tilt 6 = =
( ) ( )
( ) ( )
Tilt 7 = = Tilt 8 = =
( ) ( )
Tank Type, Capacity, Inside Diameter, and Length Data
Record this data for each tank in the spaces provided below. If the inside diameter or
length of the tank is not known, measure it carefully.
TYPE CAPACITY DIAMETER LENGTH
TANK 1
TANK 2
TANK 3
TANK 4
TANK 5
TANK 6
TANK 7
TANK 8
— ❖ —
or
