SYSTEM WIRING Page 7 - 33 7
Other Console Accessories
The following is a partial list of optional accessories that can be connected to
the console:
• Relay Output Module reference the: TS-ROM2 (dry contact) relay output
(
* ) BriteBox ® Installation Manual for complete installation details.
• Control Input Module reference the: TS-CIM control input ( * ) BriteBox ®
Installation Manual for complete installation details and available solid state
input modules, which must be ordered separately from the TS-CIM (
T1 T2 ).
The above are similar to the TS-SEM ( * ) BriteBox ® which is shown in Figure
7-8, because they use a TS-KB installation kit and connect to J11 inside the
console through the 3/4 inch SPI conduit knockout. Also reference Figure 7-1b.
• TS-KB BriteBox ® installation kit: connects a BriteBox to BriteBox, or a
BriteBox to the Console. A serial port interface (SPI) cable is included in the
assembly. Reference Figure 7-8, & Figure 7-1b / INCON Applications Bulletin
for installation.
• TS-DIM Dispenser Interface Module. See the TS-DIM Installation and Quick
Installation Guides for details.
• TS-CPM Cathodic Protection Monitor. See the TS-CPM User Guide for
Installation and Setup-Programming details.
The TS-ROM2, TS-CIM, TS-SEM, TS-KB, TS-DIM and TS-CPM are not
approved for use in European Union markets where ATEX approved
devices are required. NOTE
