SYSTEM WIRING Page 7 - 31 7
TABLE 7-5 I/O Input and Output Modules – Model Type – ( T2 )
Order
INCON P/N
MODULE TYPE DESCRIPTION
AD14ØI AC/DC Input Module 90 - to - 140 Volt AC or DC *
AD24ØI AC/DC Input Module 180 - to - 240 Volt AC or DC *
DC28I DC Input Module 2.5 - to - 28 Volt DC
DC32I DC Input Module 12 - to - 32 Volt DC
DC6ØI DC Input Module 35 - to - 60 Volt DC
AC12ØNO AC Output Module 12 - to - 120 Volt AC Normally Open
AC24ØNO AC Output Module 24 - to - 240 Volt AC Normally Open
AC24ØNC AC Output Module 24 - to - 240 Volt AC Normally Closed
DC6ØNO DC Output Module 5 - to - 60 Volt DC Normally Open
DC2ØØNO DC Output Module 5 - to - 200 Volt DC Normally Open
DRYCONNO Dry Contact Output Module Form A SPST Normally Open
DRYCONNC Dry Contact Output Module Form B SPST Normally Closed
CAUTION The TS-IEM terminal strip is rated for 1 Ampere maximum. DO
NOT exceed this rating — regardless of the module rating !
* Indicates dual purpose AC/DC Input I/O modules
Output and Dry Contact (Relay) modules are equipped with replaceable fuses...
these fuses are identical but differ between manufacturers. Supply varies with
availability.
