LEVEL PROBE INSTALLATION Page 6 - 5 6
Recording RTD/Temperature Sensor Locations (continued... )
RTD/Temperature Sensor Locations for Special Probes
RTD # – Probe 5 RTD # – Probe 6
6 6
5 5
4 4
3 3
2 2
1 1
RTD # – Probe 7 RTD # – Probe 8
6 6
5 5
4 4
3 3
2 2
1 1
The write-in fields for Tanks 5 though 8 are for the TS-2001 and TS-508 Tank
Sentinel
® consoles only (this is true throughout this manual).
TSP-LL2 Probe Models & Float Identification
The TSP-LL2 liquid level probe may be available in two versions. The probe head
shapes are different although they both perform the same function. The older
version has a black molded housing, and the newer version has an extruded
aluminum housing. Both come with a #316 stainless steel float retainer and e-ring
to hold the floats on the stainless steel shaft (see page 6 - 1 for probe description).
(
T2 T8
)
NOTE
