P Page P - ii TANK SENTINEL INSTALLATION GUIDE
Read this – Before you Begin
Product Legend (codes used in this manual):
T1
= for TS-1001 UST Tank Sentinel ® ATG and Leak Detection System
T2 = for TS-2001 UST Tank Sentinel ® ATG and Leak Detection System
T4 = for TS-504 AST Tank Sentinel ® Inventory Monitoring System
T7 = for TS-750 UST Tank Sentinel ® Tank Monitoring and Compliance Kit
T8 = for TS-508 UST Tank Sentinel ® Inventory Monitoring System
none = for all products
Abbreviations (used in this manual):
AST = for Aboveground Storage Tanks
UST = for Underground Storage Tanks
ATG = for Automatic Tank Gauge
I.S.
= for Intrinsically Safe
Unlike the TS-2001 (
T2)
, TS-1001 (
T1
) and TS-750 (
T7)
, the TS-508 (
T8
) and
TS-504 ( T4 ) are Inventory Monitoring systems that don’t support tank leak-testing,
or line leak-testing (leak-detection sensors can be interfaced with optional TS-SEM
modules).
CAUTION The probes and leak detection sensors that are connected to the
Tank Sentinel ® console may be installed in hazardous locations where flammable
vapors are present. It is essential that you read and follow all warnings and
instructions in this manual carefully to protect yourself and others from: injury,
electrical shock, explosion, and death.
The Tank Sentinel ® system is designed using principles of intrinsic safety. The
power in the wiring between the console and the liquid level probe and the leak
detection sensors is limited to a very low level. It is not possible for the electrical
energy available in this wiring to cause ignition of group D flammable vapors if the
system (ATG console, probes and sensors) have been properly installed and wired.
It is your responsibility to maintain the effectiveness of the safety features by
following the instructions in this manual. You can create a serious explosion hazard
by installing or wiring this system incorrectly.
Leaking underground storage tanks – USTs – create serious environmental
and health hazards. The (
T1, T2, T7 ) Tank Sentinel ® system is designed to
detect leaks in these tanks. You must follow the instructions in this manual
carefully to ensure that the system will be effective in detecting these leaks
and hazards.
