CONSOLE MOUNTING Page 4 - 1 4
4 Console Mounting
Console Location
To get maximum benefit from the system, locate the console where personnel
can easily make use of it — mount it at eye-level for operator convenience. The
selected location must be indoors, and in an area that is classified as
nonhazardous. The console must be well protected from rain, condensation,
extremes of temperature, severe vibration, and other conditions which could
cause damage. A typical UST system installation is shown in Figure 4-1.
Mount the console level on a vertical surface using appropriate fasteners
between 2 feet (0.6 m) and 6 feet (1.9 m) high. For European applications the
console must be located in a pollution degree 2 environment per IEC60664.
In addition, the console must be located so that the wiring, between the level
probes, and the console DOES NOT exceed 1500 feet (457.2 m). See
CAUTION and WARNING on the next page.
Product Codes: T1 = TS-1001, T2 = TS-2001, T4 = TS-504, T7 = TS-750, T8 = TS-508,
none = all products
Figure 4-1. Typical Tank Sentinel UST Installation
A C K N OW L ED G E
IN T EL L IG EN T C O NT R O LS I NC . 7 4 IN DU TR IA L P AR K R OA D SA C O, M AIN E 0 40 72
M O D E L T S - R K
T A N K O V E R F IL L A L A R M
TS-1001 TANK SENTINEL
M 1
S TA TU S
M 2
S YS TE M
O KA Y
ENV IR ONM EN TAL C ONT RO LS DI VIS IO N
M 3
TA NK
OK AY
M 4
SE NS OR
OK AY
R
F EE D R EP OR T Z M E N U 7 AL AR M L 8 Y M 9 D OW N S PA C E W
W A T ER S
P P RO DU CT
H
T AN K D 4
1 A
U I V J
U L L A G E Q E 5 R F 6
G R O S S 2 N B L E V E L O C 3
P O W E R W A R N IN G S A L A R M T E S T
K X + /- G UP T CA NC E L CA NC E L
A LA R M
NON-HAZARDOUS AREA
ACK
S H IF T TEST 0 SET U P . EN TE R
MODEL
TSP-K4A
RISER CAP
HAZARDOUS AREA
TELEPHONE LINE FOR OPTIONAL FAX/MODEM
T2 / T1 / T4
T7 / T8 TANK
SENTINEL
CONSOLE
(MODEL
T1 SHOWN)
CONDUIT FOR
INTRINSICALLY SAFE
PROBES & SENSORS
SEPARATE WEATHERPROOF
PULL BOX FOR INTRINSICALLY
SAFE PROBE AND SENSOR
CABLES ONLY
EYS SEAL FITTING
(TYPICAL)
MODEL
TSP-KI2
RISER CAP
RISER
PIPE
(SECTION A)
TANK 1
MODEL TS-RA2
REMOTE OVERFILL
ALARM UNIT
MODEL TS-RK
ACKNOWLEDGE
UNIT
ELECTRICAL POWER PANEL
TANK 1...
LEAK DETECTION
SENSOR
MODEL TSP-DIS
OR
TSP-EIS
(TS-2001 / TS-1001
CONSOLES ONLY)
(SECTION B)
...TANK 4
MODEL TSP-LL2
LIQUID LEVEL
PROBE EYS SEAL FITTING
(TYPICAL)
WEATHER-
PROOF
JUNCTION
BOX
TO
TSP-DIS
OR
TSP-EIS
(CLASS I, DIVISION 1,
GROUP D)
