INSTALLATION OVERVIEW Page 1 - 13 1
DON’T Substitute any components. Intrinsic safety could be impaired.
DON’T Drill or punch any holes in the Tank Sentinel console enclosure.
CAUTION Read the installation instructions carefully. The Tank Sentinel ®
system is designed to be safe when correctly installed. It is possible to create
explosion hazards, health hazards, risk of death, and environmental hazards
through incorrect installation.
Installation Procedure Overview – Steps
Step 1 Excavate down to the tanks to gain access to the bungs (openings) which will be
used to install the level probes, and interstitial leak detection sensors (USTs only).
Step 2 Install a 4 inch (101.6 mm) riser pipe on each tank for the level probe. This riser
must allow access into the tank. (Note: For tanks with a 2 inch (50.8 mm)bung
access, add a 4-to-2 inch (101.6 to 50.8 mm) reducer at the tank and then install a
4 inch (101.6 mm) riser. This configuration requires 2 inch (50.8 mm) floats — see
instructions provided).
Step 3 Install a 2 or 4 inch (50.8 or 101.6 mm) riser pipe (as required) on each tank for
each optional interstitial leak detection sensor. This riser must allow access to the
interstitial space between double wall tanks.
Step 4 Install a manhole around each riser (USTs only).
Step 5 Mount the Tank Sentinel console in a suitable indoor location.
Step 6 Install threaded, conduit between the manhole junction boxes, I.S. pull boxes, and
the console. Install EYS seal fittings before the pull boxes, and manhole junction
boxes (manholes apply to USTs only)
Step 7 With power off: Install the probe and sensor wiring to the Tank Sentinel console.
Use ONLY the cables and wire types specified in this manual (or the Direct Burial
Cable manual).
