7
Page
7 - 2
TANK SENTINEL
®
INSTALLATION GUIDE
RJ11 JACK
FOR OPTIONAL
INTERNAL FAX/MODEM
COMM PORT 2
RS232 DB-9P M
COMM PORT 1
RS232 DB-9S F
SOUND ALARM
(NO CONNECTION)
CONDUIT SPECIFICATIONS:
KNOCKOUTS FOR 3/4 or 1/2 INCH
CONDUIT — NON-INTRINSICALLY
SAFE WIRING ONLY !
FOR TS-IEM INTERNAL
ADD-ON MODULE
WIRING ONLY !
RUNNING INTRINSICALLY
SAFE WIRING IN THE SAME
CONDUITS AS
NON-INTRINSICALLY
SAFE (NON–I.S.) WIRING
WILL CREATE AN
EXPLOSION HAZARD.
FOR
BriteBox™ MODULE
SPI INTERFACE
(RIBBON CABLE)
WIRING ONLY !
LISTED 6L79
LIQUID LEVEL GAUGE
(
JAUGEAGE DE NIVEAU LIQUIDE
) /
LEAK DETECTION SYSTEM
(
SYSTÈME DE DÉTECTION FUITE
)
FOR FLAMMABLE LIQUID
120VA MAX
UNIT CONTAINS INTRINSICALLY SAFE
CONNECTIONS FOR
INCON MODEL PROBES, &
SENSORS LOCATED IN CLASS I, DIV 1, GROUP D
HAZARDOUS LOCATIONS. FOR USE WITH
EQUIPMENT SPECIFIED IN THE INSTALLATION
INSTRUCTIONS. SEE INSTALLATION
INSTRUCTIONS (VOIR INSTRUCTIONS D’
INSTALLATION) P.N. 000-1049.
ASSOCIATED EQUIPMENT
APPAREILLAGE CONNEXE EXI
RJ11 & RS232 PORTS (AT BOTTOM OF THE
ENCLOSURE), ARE FOR USE WITH EQUIPMENT
SPECIFIED IN THE INSTALLATION INSTRUCTIONS.
WARNING
SUBSTITUTION OF COMPONENTS
MAY IMPAIR INTRINSIC SAFETY
AVERTISSEMENT
LA SUBSTITUTION DE COMPOSANTS PEUT
COMPROMETTRE LA SÉCURITÉ INTRINSÈQUE
PN 240-1183 Rev. A
Approved
Wiring
Ratings:
1 Amp Max
up to 250
Volts Max
– or –
I/O module
voltage
rating
(whichever
is less)
M
ODEL
:
S/N:
VAC, 50 / 60 Hz
A
MPS
M
AX
: 1
INTELLIGENT CONTROLS, INC. SACO, ME 04072 USA
AUTOMATIC
TANK GAUGE
&
LEAK
DETECTION
SYSTEM
MADE IN
USA
Tank Sentinel
®
PN 240-1
187
TS-1001-P
987654321
120
Figure 7-1b.
Conduit Knockouts — Left (Hinge) Side of Consoles
NON-INTRINSICALLY SAFE WIRING ONLY !
PN 240-1184 Rev. A
FOR USE ONLY WITH EQUIPMENT SPECIFIED IN THE INSTALLATION
INSTRUCTIONS.
RJ11
RS232 DB-9P
RS232 DB-9S
NO
CONNECTOR
MALE
FEMALE
CONNECTOR
FOR
CONNECTOR
CONNECTOR
FAX/MODEM
COMM PORT 2
COMM PORT 1
ALARM HORN
LISTED 6L79
LIQUID LEVEL GAUGE
(
JAUGEAGE DE NIVEAU LIQUIDE
) /
LEAK DETECTION SYSTEM
(
SYSTÈME DE DÉTECTION FUITE
)
FOR FLAMMABLE LIQUID
120VA MAX
UNIT CONTAINS INTRINSICALLY SAFE
CONNECTIONS FOR
INCON MODEL PROBES, &
SENSORS LOCATED IN CLASS I, DIV 1, GROUP D
HAZARDOUS LOCATIONS. FOR USE WITH
EQUIPMENT SPECIFIED IN THE INSTALLATION
INSTRUCTIONS. SEE INSTALLATION
INSTRUCTIONS (VOIR INSTRUCTIONS D’
INSTALLATION) P.N. 000-1050.
OUTPUT CONTACT
{
3 AMP @ 240 VAC
RATINGS
3 AMP @ 30 VDC
ASSOCIATED EQUIPMENT
APPAREILLAGE CONNEXE EXI
WARNING
SUBSTITUTION OF COMPONENTS
MAY IMPAIR INTRINSIC SAFETY
AVERTISSEMENT
LA SUBSTITUTION DE COMPOSANTS PEUT
COMPROMETTRE LA SÉCURITÉ INTRINSÈQUE
CONDUIT SPECIFICATIONS:
NON-INTRINSICALLY SAFE WIRING
ONLY !
3/4 INCH CONDUIT KNOCKOUT
FOR
BriteBox™ MODULE
SPI INTERFACE
(RIBBON CABLE)
WIRING ONLY !
RJ11 & RS232 PORTS (AT BOTTOM OF THE
ENCLOSURE), ARE FOR USE WITH EQUIPMENT
SPECIFIED IN THE INSTALLATION INSTRUCTIONS.
PN 240-1188 Rev. A
M
ODEL
:
S/N:
VAC, 50 / 60 Hz
A
MPS
M
AX
: 1
INTELLIGENT CONTROLS, INC. SACO, ME 04072 USA
AUTOMATIC
TANK GAUGE
&
LEAK
DETECTION
SYSTEM
MADE IN
USA
Tank Sentinel
®
PN 240-1
187
TS-1001-P
987654321
120
TS-1001, TS-504, TS-508, TS-750
(
T1, T7
), printer is optional with the (
T4 T8
)
TS-2001
(
T2
)
(
T1 T2
)
Figure 7-1c.
Communication Connectors — Console Bottom View
= 1/2 OR 3/4" (12.8 or 19 mm)
CONDUIT KNOCKOUTS FOR
NON-INTRINSICALLY SAFE
WIRING ONLY:
C
C
Console Model & Serial Number
label (includes AC line voltage
requirement)
OPTIONAL
(ADD-ON)
INTERNAL
EXPANSION
MODULE(S)
OPTIONAL
BRITEBOX
MODULE
(SPI INTERFACE)
C
# 2
C
C
C
# 1
C
