INSTALLATION OVERVIEW Page 1 - 5 1
Product Description — TS-1001
The INCON Tank Sentinel model TS-1001 (
T1
) is a complete, automatic inventory
monitoring and leak detection system for up to 4 underground storage tanks. It
performs these important functions simultaneously. A basic TS-1001 Automatic
Tank Gauge (ATG) and Leak Detection System consists of a wall-mounted
console, magnetostrictive liquid level probes (one for each tank), and probe
installation kits. There are many additional optional hardware and software
upgrades that are available for the system. The TS-1001:
• conducts highly accurate, 99.9% Pd @ 0.2 gph(0.76 lph), third-party approved, in-
tank volumetric leak tests on demand or on an automatic schedule for EPA
compliance reporting (this helps prevent environmental contamination)
• monitors deliveries, inventory levels, thefts, and other conditions (such as: high
water levels, low product levels, reorder product levels, and full and over-full
product levels)
• generates reports automatically in response to preset/programmed conditions and
alarms
• provides audio / visual annunciation when an alarm or warning condition exists
• enhances site-management by increasing efficiency, and by providing the data to
make intelligent business choices
• can display / printout in several languages (English, French, Spanish, Portuguese)
• interfaces with external audio/visual alarms with two form-C relay outputs (std)
• monitors up to 8 optional TS-LLD line leak detectors for EPA compliance reporting
and for positive pump shutdown when a leak is detected
• communicates to external locations in response to preset/programmed conditions
or alarms, and communicates bidirectionally during data acquisition if an optional
plug-in modem / fax-modem is installed inside the console
• provide positive, pump shutdown with an optional TS-ROM BriteBox
• detects external product leaks with optional, approved, leak detection sensors (see
TABLE 1.2)... up to 12 sensors can be wired internally, and an additional 8 or 16
sensors can be wired to 1 or 2 optional, external TS-SEM BriteBoxes (see
Chapter 7 about the TS-SEM)
• monitors precise tank inventory and sales data when an optional TS-DIM dispenser
interface module is installed
• conducts statistical tank leak tests continuously for EPA compliance reporting
(useful in busy / 24 hour sites) with the optional SCALD software upgrade
• monitors emergency generator sites and runs tank leak tests continuously for EPA
compliance reporting with the optional Generator software
• can be used for chemical applications with chemical probes. The TSP-LL2C is a
TSP-LL2 probe with Stainless Steel (SS): swagelock fitting, install kit, and float.
This list identifies many of the TS-1001 capabilities, but may not be all-inclusive.
