Appendix A Page A - 1 A
A Appendix A System
Technical Specifications
CMH
1586
Operating Specifications
Applicable Liquid Products
Petroleum (all), most chemicals, and
hazardous wastes when used with
appropriate liquid floats (consult
factory).
Number of Tanks Monitored (Liquid Level)
0 ( T1 ), 1 to 2 or 1 to 4 ( T1 T4 ), or
1 to 8 ( T2 T8 )
Model TSP-LL2 Liquid Level Probes
[EE
X
ia] IIA T4:
Accuracy +/– 0.025 % of full scale
Resolution 0.001” (0.025mm) or better
Temperature Resolution 0.001°F
(0.0006°C) or better
Measurement Circuit Stability +/– 25
PPM over full operating temperature
Stability +/– 3 PPM per degree Fahrenheit
+/-5.4 PPM per degree Celsius
Number of Temperature Sensors / RTD'S
0 to 6 (5 standard per probe), with
automatic rejection of temperature
sensors above liquid level
Tank Leak Test Time (
T1 T2
)
Depends on the leak test precision,
confidence level, and various
conditions within the tank.
Number of Leak Detection Sensors:
1 to 12 (
T1
) or to 24 (
T2
) internally,
—20 or 28 (
T1
) or 32 or 40 (
T2
) with
one or two optional external TS-SEM
BriteBoxes
® (8 or 16 for T4 T8 ).
Leak Detection Sensor Models
UL & CUL A
SSOCIATED
E
QUIPMENT
T
EMP
C
ODE
T3C:
3 Wire BriteSensors ® :
TSP-DDS, TSP-DIS, TSP-DVS,
TSP-DTS, TSP-HIS, TSP-MWS
2 Wire Standard Sensors:
TSP-HLS, TSP-ULS
3 Wire Standard Sensor: TSP-EIS
Safety
Intrinsically safe circuits for liquid level
probes, and leak detection sensors
mounted in: Class I, Division 1, Group
D hazardous locations. [EEx ia] IIA
Mechanical Specifications
Dimensions in inches (mm)
w/o printer:
( T1 T4 T7 T8 )
12(305) H x 11(279) W x 4(102) D
(
T2 ) 12(305) H x 17(432) W x 6(152) D
with optional printer:
( T1 T4 T7 T8 )
12(305) H x 11(279) W x 4.5(114) D
(
T2 ) 12(305) H x 17(432) W x 6.5(165) D
Display ( Backlit LCD )
Alphanumeric Liquid Crystal Display 2
rows of 40 characters
6L79
Product Codes:
T1
= TS-1001,
T2
= TS-2001,
T4
= TS-504,
T7
= TS-750,
T8
= TS-508, none = all products
T1 & T2 only All Products
II (1) G
[EEx ia] IIA
0539
