LEVEL PROBE INSTALLATION Page 6 - 9 6
Final Level Probe Installation Steps
1) Leave a six inch (152.4 mm) cable service loop between the rubber grommet in the
steel support plate and the compression gland fitting at the TSP-K4A riser cap (see
Figure 6-1).
2) Tighten the riser cap compression fitting so that it grips the cable tightly and forms
a watertight seal (see Figure 6-1).
3) Push the probe’s cable through the compression gland fitting at the weatherproof
junction box. Make sure that you leave enough cable from the level probe to the
junction box (tye-wrap a coiled service loop) so that the probe can be easily be
removed and reinstalled without rewiring and splicing.
4) Tighten the compression gland fitting at the junction box so that it grips the cable
tightly and forms a watertight seal.
5) Lastly, position the TSP-K4A cover on the riser cap adapter and snap it in place.
You may install a bolt or lock through the lock-holes at the cover to secure it in a
closed position.
— ❖ —
