Chapter 5 View

NetAtlas Workgroup User’s Guide

62

The following table describes the labels in this screen.

5.4 Port Status

Follow the steps below to view the port status of a switch.

1 Click View > Port Status.
2 To view the port status of a switch choose a switch from the list located on the left-hand

side of the screen.

Table 18 View: VLAN Status

LABEL

DESCRIPTION

Device Name

This field displays the descriptive name of a device.

Device IP

This field displays the IP address of a device

VLAN ID

This field displays the identification number of the VLAN.

Name

This field displays a unique number for identification purposes.

Elapsed Time

This field displays the time since the VLAN was created.

Status

This field displays Static if the VLAN is active and will remain so after the next reset

of the device. This field displays GVRP if the VLAN is active and will remain so until

removed by GVRP. This field is Other if the VLAN is active, but is not permanent or

created by GVRP.

Previous Page

Click Previous Page to display the previous VLAN ID screen.

Next Page

Click Next Page to display the next VLAN ID screen.

Current Page

This field displays the current page number.
Enter a number and click Show Page to display that page.

VLANs/Page

This field displays the number of VLAN entries to display in one page.
Enter a number (1-99) and click Show Page to display that number of VLAN entries

in a page.

Port List

This table displays port VLAN settings. A tagged port is marked T, an untagged port is

marked U and a port not participating in a VLAN is marked -.

Polling

The text box displays how often (in seconds) this screen refreshes. You may change

the refresh interval by typing a new number in the text box and then clicking the

Apply button.

Close

Click Close to close the screen.
