Chapter 2 Main EMS Screen

NetAtlas Workgroup User’s Guide

39

Figure 11 Admin: SNMP Operation Mode

The following table describes the fields in this screen.

2.5 Accessing the Switch Manager Screen

To display the EMS main screen, click on the device icon in the main screen.
The EMS polls for all the available switches. Select a device icon to display a graphic of the
switch in the Device Panel. You can only display one switch in the Device Panel at one time.

Table 7 Admin: SNMP Operation

LABEL

DESCRIPTION

Client Sends SNMP

Operation via Server

Select this option to set the EMS remote client computer(s) to send SNMP

messages to managed ZyXEL devices through the EMS server.
Select this option if the remote client computer(s) is not in the same subnet as

the managed devices.

Client Sends SNMP

Operation itself

Select this option to allow the EMS remote client computer(s) to send SNMP

messages directly to managed ZyXEL devices.
Select this option if the remote client computer(s) is in the same subnet as the

managed devices.

OK

Click OK to save changes to the EMS.

Cancel

Click Cancel to discard the change and close the screen.
