NetAtlas Workgroup User’s Guide
163
C
H A P T E R
16
Ethernet Port Configuration
This chapter shows how to configure the Ethernet port settings.
16.1 Overview
Use the Ethernet Port Configuration screens to set port-related settings (such as port VLAN,
STP and security, etc.).
Once you configure a feature on a port, you must enable that feature on the switch in the
Switch Setup screen.
16.2 Port Setup
Use the Port Setup screen to activate and configure switch port settings.
To open this screen, right-click on the switch in the Device List Panel, and click
Configuration > Ethernet Port > Port Setup. Then select a device and the port(s) to which
you want to apply this configuration.
Figure 114 Ethernet Port Configuration: Port Setup
