Chapter 16 Ethernet Port Configuration

NetAtlas Workgroup User’s Guide

172

The following table describes the fields in this screen.

16.10 Protocol VLAN

Protocol based VLANs allow you to group traffic into logical VLANs based on the protocol
you specify. When an upstream frame is received on a port (configured for a protocol based
VLAN), the switch checks if a tag is added already and its protocol. The untagged packets of
the same protocol are then placed in the same protocol based VLAN. One advantage of using
protocol based VLANs is that priority can be assigned to traffic of the same protocol.

Note: Protocol based VLAN applies to un-tagged packets and is applicable only when

you use IEEE 802.1Q tagged VLAN.

To open the Protocol VLAN screen, right-click on the switch in the Device List Panel, and
click Configuration > Ethernet Port > Protocol VLAN. Then select a device and the port(s)
to which you want to apply this configuration.

Table 87 Ethernet Port Configuration: Queue Method

LABEL

DESCRIPTION

Q0 - Q7

For Weighted Fair Scheduling, select the queue weight here. Bandwidth is

divided across the different traffic queues according to their weights. Queues with

larger weights get more guaranteed bandwidth than queues with smaller weights.
For Gigabit/ Mini-GBIC ports, if you select 0 for the queue weight, the switch uses

Strictly Priority to service the queue.

GE Port SPQ

Enable

SPQ

Select SPQ (Strict Priority Queuing) to service queues based on priority only.

When the highest priority queue empties, traffic on the next highest-priority queue

begins. The default queuing method is Strictly Priority.
Weighted Fair Scheduling
is used to guarantee each queue's minimum

bandwidth based on their bandwidth portion (weight) (the number you configure

in the Weight field). Queues with larger weights get more guaranteed bandwidth

than queues with smaller weights.

WRR

Select WRR (Weighted Round Robin Scheduling) to service queues on a rotating

basis based on their queue weight (the number you select from the drop-down list

box for the corresponding queue). Queues with larger weights get more service

than queues with smaller weights.

Apply

Click Apply to save the changes.
