Chapter 19 IP Configuration

NetAtlas Workgroup User’s Guide

218

The following table describes the labels in this screen.

19.9.2 Configuring a VRRP Interface

1 In the Device Panel list, right-click on a device.
2 Click Configuration > IP Configuration > VRRP.

Table 122 IP Configuration: VRRP

LABEL

DESCRIPTION

Index

This field displays the index number of an entry.

Network

This field displays the IP address and number of subnet mask bit of an IP domain.

Authentication

Select None to disable authentication. This is the default setting.
Select Simple to use a simple password to authenticate VRRP packet exchanges

on this interface.

Key

When you select Simple in the Authentication field, enter a password key (up to

eight printable ASCII character long) in this field.

Apply

Click Apply to save the changes.

Index

This field displays the index number of an entry.

Active

This field shows whether a VRRP entry is enabled (Yes) or disabled (No).

Name

This field displays a descriptive name of an entry.

Network

This field displays the IP address and subnet mask of an interface.

VRID

This field displays the ID number of a virtual router.

Primary VIP

This field displays the IP address of the primary virtual router.

Uplink Gateway

This field displays the IP address of the uplink gateway.

Priority

This field displays the priority level (1 to 255) of the entry.

Add

Click Add to create a new VRRP interface.

Modify

Click Modify to change the settings of the selected VRRP interface.

Delete

Click Delete to remove the selected VRRP interface.
