Chapter 4 Map

NetAtlas Workgroup User’s Guide

55

4.1.2 Editing a Node

Select a device or submap icon in the Device List Panel and then click Map > Edit Node.

Figure 22 Map: Edit Node

Refer to

Table 13 on page 54

for the field descriptions.

4.1.3 Finding an Object

To find or locate a device (or node), click Map > Find Object.

Figure 23 Map: Find Object

Enter a descriptive text (for example, the node name) in the Find What field and click OK to
start the search.

4.1.4 Deleting a Submap

To delete a submap, select the submap icon in the Device List Panel and click Map > Delete.

OK

Click OK to save the changes and close the screen.

Cancel

Click Cancel to discard the changes and close the screen.

Table 13 Map: Add Submap/Device (continued)

LABEL

DESCRIPTION
