The following table describes the labels in this screen.
17.2.2 Applying a Multicast Template
After you create a multicast template using the Template screen, you can apply the template to
the switch in the Multicast Setting screen.
"
When you apply a multicast template, all custom port multicast settings will be
erased.
In the Multicast Setting screen, select a device in the device list panel and click Load
Template. A screen displays as shown.
Table 94 Multicast Configuration: Multicast Settings: Modify
LABEL DESCRIPTION
Port This field displays the port number.
Immed. Leave Select this option to set the switch to remove this port from the multicast tree when
an IGMP version 2 leave message is received on this port.
Select this option if there is only one host connected to this port.
Group Limited Select this option to limit the number of multicast groups this port is allowed to join.
Max Group Num. Enter the number of multicast groups this port is allowed to join. Once a port is
registered in the specified number of multicast groups, any new IGMP join report
frame(s) is dropped on this port.
Enter 0 to allow a port to join any number of multicast groups.
IGMP Filtering
Profile
Select the name of the IGMP filtering profile to use for this port. Otherwise select
Default to prohibit the port from joining any multicast group.
IGMP Querier
Mode
The switch treats an IGMP query port as being connected to an IGMP multicast
router (or server). The switch forwards IGMP join or leave packets to an IGMP
query port.
Select Auto to have the switch use the port as an IGMP query port if the port
receives IGMP query packets.
Select Fixed to have the switch always use the port as an IGMP query port. Select
this when you connect an IGMP multicast server to the port.
Select Edge to stop the switch from using the port as an IGMP query port. The
switch will not keep any record of an IGMP router being connected to this port.
The switch does not forward IGMP join or leave packets to this port.
OK Click OK to save your changes and close this screen.
Cancel Click Cancel to discard all changes and close this screen.
