Chapter 2 Main EMS Screen
NetAtlas Workgroup User’s Guide
35
2.3 Database Management
The following information is stored in the EMS database.
• Event and access logs
• EMS configuration
• Device configuration and status information
Use the Database Management screens to back up logs and EMS and SNMPc configurations
and restore selected backed up files.
2.3.1 Database Synchronization
The EMS is able to synchronize the device tree and device status information with SNMPc.
This means that when you add a device in EMS, the same change also applies in SNMPc and
the new device icon is created in both the EMS and SNMPc screens. In addition, device status
changes are reflected in both the EMS and the SNMPc screens.
EMS database is synchronized:
• when you launch the Switch Manager screen.
• when you click Map > Sync Map DB in EMS.
• automatically everyday at mid-night (this schedule is not configurable).
2.3.2 Filename Convention
The EMS follows a pre-defined naming convention for backup files. Data is backed up in plain
text format with a “txt” filename extension. The general structure of the filename is
.txt (for example, AccessLog.txt ).
Date Select a start date and end date from the list boxes to display logs for that period.
Apply Click Apply to display logs with the criteria set above.
Index This field displays the log number.
Target This field displays a reason for the generated log.
Device
Name
This field displays name of the switch that generated the log(s).
Log Type This field displays the type of log the switch generated.
Log Time This field displays the time a log was generated by a switch.
Login User This field displays the EMS user that logged into the switch
Slot This field is currently not supported.
Port This field displays the selected switch port number on which the log was generated.
Description This field displays further information about the log.
Delete Click Delete to delete a selected log from the list of log entries.
Close Click Close to close this screen.
Table 3 Admin: Access Log (continued)
LABEL DESCRIPTION
