5.3 VLAN Status
Follow the steps below to view the VLAN status of a switch.
"
The VLAN Status screen only displays static IEEE 802.1q VLAN information.
1 Click View > VLAN Status.
2 Choose a switch from the list located on the left-hand side of the screen.
Figure 27 View: VLAN Status
Topology
Changed Times
This is the number of times the spanning tree has been reconfigured.
Time Since Last
Change
This is the time since the spanning tree was last reconfigured.
Polling The text box displays how often (in seconds) this screen refreshes. You may
change the refresh interval by typing a new number in the text box and then
clicking the Apply button.
Close Click Close to close the screen.
Table 17 View: STP Status (continued)
LABEL DESCRIPTION
