P-793H User’s Guide
Appendix A Product Specifications 365
Appendix A
Product Specifications
Table 137 Device
Default IP Address 192.168.1.1
Default Subnet Mask 255.255.255.0 (24 bits)
Default Password 1234
DHCP Pool 192.168.1.33 to 192.168.1.64
Dimensions (W x D x H) 180 x 128 x 36 mm
Power Specification 12V AC 1A
Built-in Switch Four auto-negotiating, auto MDI/MDI-X 10/100 Mbps RJ-45 Ethernet ports
G.SHDSL Port RJ-11 interface
Data Rate: 192 Kbps - 5700 Kbps, 192-11400kbps (4-wire mode)
Line Code: TC-PAM modulation
Line Impedance: 135 W
Connection Loops: one pair (2-wire) or two pairs (4-wire)
Operation Temperature 0º C ~ 40º C
Storage Temperature -20º ~ 60º C
Operation Humidity 20% ~ 90% RH
Storage Humidity 10% ~ 90% RH
Distance between the
centers of the holes on
the device’s back.
108 mm
Screw size for wall-
mounting
M3*10
Table 138 Firmware
Routing/Bridge Support IP (RFC 791) routing is supported.
TCP, UDP, ICMP, IGMP v1 and v2, ARP, RIP v1, RIP v2
Transparent bridging (IEEE 802.1D)
PPP BCP (RFC 3185) support
G.SHDSL TC-PAM line modulation
Configurable as either server or client mode
Rate negotiating / Manually rate adaptation configuration
2-wire and 4-wire mode auto detect
- Data Rate Selections: From 192 kbps to 5700 kbps (2-wire mode)
- Data Rate Selections: From 192 kbps to 11400 kbps (4-wire mode)
