P-793H User’s Guide
Chapter 30 Filter Configuration 309
30.3 Example Filter
Let’s look at an example to block outside users from accessing the ZyXEL Device via telnet.
Please see our included disk for more example filters.
Figure 189 Telnet Filter Example
1 Enter 21 from the main menu to open Menu 21 - Filter and Firewall Setup.
2 Enter 1 to open Menu 21.1 - Filter Set Configuration.
3 Enter the index of the filter set you wish to configure (say 3) and press [ENTER] .
4 Enter a descriptive name or comment in the Edit Comments field and press [ENTER].
5 Press [ENTER] at the message [Press ENTER to confirm] to open Menu 21.1.3 - Filter
Rules Summary.
6 Enter 1 to configure the first filter rule (the only filter rule of this set). Make the entries in
this menu as shown in the following figure.
Log Select the logging option from the following:
None - No packets will be logged.
Action Matched - Only packets that match the rule parameters will be logged.
Action Not Matched - Only packets that do not match the rule parameters will be logged.
Both – All packets will be logged.
Action
Matched
Select the action for a packet matching the rule.
Options are Check Next Rule, Forward and Drop.
Action Not
Matched
Select the action for a packet not matching the rule.
Options are Check Next Rule, Forward and Drop.
Once you have completed filling in Menu 21.1.1.1 - Generic Filter Rule, press [ENTER] at the
message “Press ENTER to Confirm” to save your configuration, or press [ESC] to cancel. This data will
now be displayed on Menu 21.1.1 - Filter Rules Summary.
Table 115 Menu 21.1.1.1: Generic Filter Rule (continued)
FIELD DESCRIPTION
