P-793H User’s Guide
Chapter 28 NAT Setup
291
Figure 168 Menu 4: Internet Access & NAT Example
From menu 4 shown above, simply choose the SUA Only option from the Network Address
Translation field. This is the Many-to-One mapping discussed in
.
The SUA Only read-only option from the Network Address Translation field in menus 4
and 11.3 is specifically pre-configured to handle this case.
28.4.2 Example 2: Internet Access with an Default
Server
Figure 169 NAT Example 2
In this case, you do exactly as above (use the convenient pre-configured SUA Only set) and
also go to menu 15.2.1 to specify the Default Server behind the NAT as shown in the next
figure.
Menu 4 - Internet Access Setup
ISP's Name= MyISP
Encapsulation= ENET ENCAP
Multiplexing= LLC-based
VPI #= 0
VCI #= 33
ATM QoS Type= UBR
Peak Cell Rate (PCR)= 0
Sustain Cell Rate (SCR)= 0
Maximum Burst Size (MBS)= 0
My Login= N/A
My Password= N/A
ENET ENCAP Gateway= 0.0.0.0
IP Address Assignment= Static
IP Address= 0.0.0.0
Network Address Translation= SUA Only
Address Mapping Set= N/A
