P-793H User’s Guide
Chapter 24 LAN Setup 261
C
H A P T E R
24
LAN Setup
Use this to apply LAN filters, configure LAN DHCP and TCP/IP settings, and to activate or
deactivate VLAN on each LAN port.
24.1 Accessing the LAN Menus
From the main menu, enter 3 to open Menu 3 - LAN Setup.
Figure 142 Menu 3: LAN Setup
24.2 LAN Port Filter Setup
This menu allows you to specify the filter sets that you wish to apply to the LAN traffic. You
seldom need to filter the LAN traffic, however, the filter sets may be useful to block certain
packets, reduce traffic and prevent security breaches.
Figure 143 Menu 3.1: LAN Port Filter Setup
Menu 3 - LAN Setup
1. LAN Port Filter Setup
2. TCP/IP and DHCP Setup
6. Port Based VLAN Setup
Menu 3.1 - LAN Port Filter Setup
Input Filter Sets:
protocol filters=
device filters=
Output Filter Sets:
protocol filters=
device filters=
