P-793H User’s Guide
142 Chapter 9 Firewall Configuration
Refer to Section 8.1 on page 119 for more information.
Figure 60 Firewall > Rules > Add/Edit > Edit Customized Services > Edit
The following table describes the labels in this screen.
9.8 Example Firewall Rule
The following Internet firewall rule example allows a hypothetical “MyService” connection
from the Internet.
1 Click Security > Firewall > Rules.
2 Select WAN to LAN in the Packet Direction field.
Table 42 Firewall > Rules > Add/Edit > Edit Customized Services > Edit
LABEL DESCRIPTION
Config
Service Name Type a unique name for your custom port.
Service Type Choose the IP port (TCP, UDP or TCP/UDP) that defines your customized port from
the drop down list box.
Port
Configuration
Type Click Single to specify one port only or Port Range to specify a span of ports that
define your customized service.
Port Number Type a single port number or the range of port numbers that define your customized
service.
Apply Click Apply to save your customized settings and exit this screen.
Cancel Click Cancel to return to the previous screen.
Delete Click Delete to delete the current rule and return to the previous screen.
