P-793H User’s Guide
Chapter 23 WAN Setup 259
Figure 141 Menu 2.2.1: Advanced Dial Backup Setup
The following table describes fields in this menu.
Menu 2.2.1 - Advanced Dial Backup Setup
AT Command Strings: Call Control:
Dial= atd Dial Timeout(sec)= 60
Drop= ~~+++~~ath Retry Count= 0
Answer= ata Retry Interval(sec)= N/A
Drop Timeout(sec)= 20
Drop DTR When Hang Up= No Call Back Delay(sec)= 15
AT Response Strings:
CLID= NMBR =
Called Id=
Speed= CONNECT
Table 96 Menu 2.2.1: Advanced Dial Backup Setup
FIELD DESCRIPTION
AT Command
Strings:
Dial Enter the AT Command string to make a call.
Drop Enter the AT Command string to drop a call. “~” represents a one second wait,
e.g., “~~~+++~~ath” can be used if your modem has a slow response time.
Answer Enter the AT Command string to answer a call.
Drop DTR When
Hang Up
Press the [SPACE BAR] to choose either Yes or No. When Yes is selected (the
default), the DTR (Data Terminal Ready) signal is dropped after the “AT
Command String: Drop” is sent out.
AT Response
Strings:
CLID (Calling Line
Identification)
Enter the keyword that precedes the CLID (Calling Line Identification) in the AT
response string. This lets the ZyXEL Device capture the CLID in the AT
response string that comes from the WAN device. CLID is required for CLID
authentication.
Called Id Enter the keyword preceding the dialed number.
Speed Enter the keyword preceding the connection speed.
Call Control
Dial Timeout (sec) Enter a number of seconds for the ZyXEL Device to keep trying to set up an
outgoing call before timing out (stopping). The ZyXEL Device times out and
stops if it cannot set up an outgoing call within the timeout value.
Retry Count Enter a number of times for the ZyXEL Device to retry a busy or no-answer
phone number before blacklisting the number.
Retry Interval (sec) Enter a number of seconds for the ZyXEL Device to wait before trying another
call after a call has failed. This applies before a phone number is blacklisted.
Drop Timeout (sec) Enter a number of seconds for the ZyXEL Device to wait before dropping the
DTR signal if it does not receive a positive disconnect confirmation.
Call Back Delay
(sec)
Enter a number of seconds for the ZyXEL Device to wait between dropping a
callback request call and dialing the corresponding callback call.
