P-793H User’s Guide
Chapter 33 System Information & Diagnosis 325
33.5 Diagnostic
The diagnostic facility allows you to test the different aspects of your ZyXEL Device to
determine if it is working properly. Menu 24.4 allows you to choose among various types of
diagnostic tests to evaluate your system, as shown next. Not all fields are available on all
models.
Follow the procedure below to get to Menu 24.4 - System Maintenance - Diagnostic.
1 From the main menu, select option 24 to open Menu 24 - System Maintenance.
2 From this menu, select option 4. Diagnostic. This will open Menu 24.4 - System
Maintenance - Diagnostic.
Figure 205 Menu 24.4: System Maintenance - Diagnostic
The following table describes the labels in this screen.
Menu 24.4 - System Maintenance - Diagnostic
xDSL System
1. Reset xDSL 21. Reboot System
22. Command Mode
TCP/IP
12. Ping Host
Enter Menu Selection Number:
Host IP Address= N/A
Table 121 Menu 24.4: System Maintenance - Diagnostic
FIELD DESCRIPTION
Reset xDSL Enter 1 to reset the DSL connection on the WAN port.
Ping Host Enter 12 to ping any machine (with an IP address) on your LAN or WAN.
Enter its IP address in the Host IP Address field below.
Reboot System Enter 11 to reboot the ZyXEL Device.
Command Mode Enter 22 to go to the Command Interpreter (CI) for further diagnosis. You can
also enter the CI using menu 24.8.
Host IP Address If you entered 1in the Enter Menu Selection Number field, then enter the IP
address of the computer you want to ping in this field.
Enter the number of the selection you would like to perform or press [ESC] to cancel.
