P-793H User’s Guide
354 Chapter 36 IP Routing Policy Setup
Figure 235 IP Routing Policy Example
To force Web packets coming from clients with IP addresses of 192.168.1.33 to 192.168.1.64
to be routed to the Internet via the WAN port of the ZyWALL, follow the steps as shown next.
1 Create a rule in Menu 25.1 - IP Routing Policy Setup as shown next.
Figure 236 IP Routing Policy Example 1
2 Select Yes in the LAN field in menu 25.1.1 to apply the policy to packets received on the
LAN port.
3 Check Menu 25 - IP Routing Policy Summary to see if the rule is added correctly.
Menu 25.1.1 - IP Routing Policy
Policy Set Name= example1
Active= Yes
Criteria:
IP Protocol = 6
Type of Service= Don't Care Packet length= 10
Precedence = Don't Care Len Comp= Equal
Source:
addr start= 192.168.1.33 end= 192.168.1.64
port start= 0 end= N/A
Destination:
addr start= 0.0.0.0 end= N/A
port start= 80 end= 80
Action= Matched
Gateway addr = 192.168.1.1 Log= No
Type of Service= Max Thruput
Precedence = 0
