P-793H User’s Guide
Chapter 36 IP Routing Policy Setup 355
4 Create another rule in menu 25.1 for this rule to route packets from any host (IP=0.0.0.0
means any host) with protocol TCP and port FTP access through another gateway
(192.168.1.100).
Figure 237 IP Routing Policy Example 2
5 Check Menu 25 - IP Routing Policy Summary to see if the rule is added correctly.
Menu 25.1.1 - IP Routing Policy
Policy Set Name= example2
Active= No
Criteria:
IP Protocol = 6
Type of Service= Don't Care Packet length= 10
Precedence = Don't Care Len Comp= Equal
Source:
addr start= 0.0.0.0 end= N/A
port start= 0 end= N/A
Destination:
addr start= 0.0.0.0 end= N/A
port start= 20 end= 21
Action= Matched
Gateway addr = 0.0.0.0 Log= No
Type of Service= No Change
Precedence = No Change
