P-793H User’s Guide
306
Chapter 30 Filter Configuration
The following figure illustrates the logic flow of an IP filter.
Port # Comp
Press [SPACE BAR] and then [ENTER] to select the comparison to apply to the
source port in the packet against the value given in Source: Port #.
Options are None, Equal, Not Equal, Less and Greater.
TCP Estab
This field is applicable only when the IP Protocol field is 6, TCP. Press [SPACE
BAR] and then [ENTER] to select Yes, to have the rule match packets that want to
establish a TCP connection (SYN=1 and ACK=0); if No, it is ignored.
More
Press [SPACE BAR] and then [ENTER] to select Yes or No. If Yes, a matching
packet is passed to the next filter rule before an action is taken; if No, the packet is
disposed of according to the action fields.
If More is Yes, then Action Matched and Action Not Matched will be N/A.
Log
Press [SPACE BAR] and then [ENTER] to select a logging option from the following:
None – No packets will be logged.
Action Matched - Only packets that match the rule parameters will be logged.
Action Not Matched - Only packets that do not match the rule parameters will be
logged.
Both – All packets will be logged.
Action Matched
Press [SPACE BAR] and then [ENTER] to select the action for a matching packet.
Options are Check Next Rule, Forward and Drop.
Action Not
Matched
Press [SPACE BAR] and then [ENTER] to select the action for a packet not
matching the rule.
Options are Check Next Rule, Forward and Drop.
When you have Menu 21.1.1.1 - TCP/IP Filter Rule configured, press [ENTER] at the message “Press
ENTER to Confirm” to save your configuration, or press [ESC] to cancel. This data will now be
displayed on Menu 21.1.1 - Filter Rules Summary.
Table 114 Menu 21.1.1.1: TCP/IP Filter Rule
FIELD
DESCRIPTION
