P-793H User’s Guide
Chapter 12 Static Route 183
C
H A P T E R
12
Static Route
This chapter shows you how to configure static routes for your ZyXEL Device.
12.1 Static Route
Each remote node specifies only the network to which the gateway is directly connected, and
the ZyXEL Device has no knowledge of the networks beyond. For instance, the ZyXEL
Device knows about network N2 in the following figure through remote node Router 1.
However, the ZyXEL Device is unable to route a packet to network N3 because it doesn't
know that there is a route through the same remote node Router 1 (via gateway Router 2). The
static routes are for you to tell the ZyXEL Device about the networks beyond the remote
nodes.
Figure 86 Example of Static Routing Topology
12.2 Configuring Static Route
Use this screen to look at static routes in the ZyXEL Device. Click Advanced > Static Route
to open the Static Route screen.
